Secondary Dwelling Units

The suite must be separated by a fire separation having not less than a 45 minute fire resistance rating, Division B, Sentence 9.10.9.14. Separation of Residential Suites (1) Except as provided in Sentences (2) and (3) and Article 9.10.20.2., suites in residential occupancies shall be separated from adjacent rooms and suites by a fire separation having a fire-resistance rating of not less than 45 min.

(1) Except as provided in Sentences (2) and (3) and Article 9.10.21.2., suites in residential occupancies shall be separated from adjacent rooms and suites by a fire separation having a fire-resistance rating of not less than 45 min.

(2) Sleeping rooms in boarding, lodging or rooming houses where sleeping accommodation is provided for not more than 8 boarders or lodgers shall be separated from the remainder of the floor area by a fire separation having a fire-resistance rating of not less than 30 min where the sleeping rooms form part of the proprietor's residence and do not contain cooking facilities.

(3) Dwelling units that contain 2 or more storeys including basements shall be separated from the remainder of the building by a fire separation having a fire-resistance rating of not less than 1 h.

If the house was built before 2010, the fire separation ratings for floors can be reduced to 15 minutes; where the existing ceiling is finished with drywall and the smoke alarms are interconnected and hardwired to the other smoke alarms in the building. The fire separation rating for the walls can be reduced to 30 minutes, where the walls are existing; (new walls will require 45 min protection; type X drywall)

Houses built after 2010 require separate heating facilities for each suite. In houses constructed before 2010, where the furnace will be shared; a duct-type smoke detector must be located in the supply or return air plenum, which is triggered to shut off the furnace when smoke is present.

(1) Except as provided in Sentence (2) and Article 9.10.10.5., fuel-fired appliances other than fireplaces shall be located in a service room separated from the remainder of the building by a fire separation having not less than a 1 h fire-resistance rating.

(2) Except as required in the appliance installation standards referenced in Sentences 6.2.1.4.(1) and 9.33.1.2.(1), fuel-fired space-heating appliances, space-cooling appliances and service water heaters need not be separated from the remainder of the building as required in Sentence (1) where the equipment serves,

(a) not more than one room or suite, or

(b) a building with a building area of not more than 400 m2 and a building height of not more than 2 storeys.

Each suite must have an entrance/exit door conforming to the OBC. If a shared corridor is proposed, a second exit is required from each suite; windows are not sufficient as a second exit. A sliding door/patio door cannot be the primary exit.

The basement bedroom window should be accessible as a fire escape.

Bedroom Windows (1) Except where a door on the same floor level as the bedroom provides direct access to the exterior, every floor level containing a bedroom in a suite shall be provided with

(a) at least 1 outside window that can be opened from the inside without the use of tools, and

(b) each such window shall provide an individual, unobstructed open portion having a minimum area of 0.35 m5 (3.8 ft2) with no dimension less than 380 mm (15 in).

Hard wired smoke alarms are required.

(1) Within dwelling units, sufficient smoke alarms shall be installed so that

(a) there is at least one smoke alarm on each floor level, including basements, that is 900 mm (2 ft 11 in) or more above or below an adjacent floor level,

(b) each bedroom is protected by a smoke alarm either inside the bedroom or, if outside, within 5 m (16 ft 5 in), measured following corridors and doorways, of the bedroom door, and

(c) the distance, measured following corridors and doorways, from any point on a floor level to a smoke alarm on the same level does not exceed 15 m (49 ft 3 in).

(2) Smoke alarms required in Article 9.10.19.1. and Sentence (1) shall be installed on or near the ceiling.

(3) Smoke alarms required in Sentences (1) and (2) shall be audible within the bedrooms when the intervening doors are closed.

(4) Smoke alarms required in Sentences (1) and (2) shall be installed in conformance with the manufacturers instructions.

(1) Except as permitted in Sentence (2), smoke alarms shall be installed by permanent connections to an electrical circuit and shall have no disconnect switch between the overcurrent circuit device and the smoke alarm.

(2) Where the building is not supplied with electrical power, smoke alarms are permitted to be battery operated.

The electrical breaker panel for the secondary dwelling unit should be located in that unit, Rule 26-400 Ontario Electrical Safety Code.

Separate water shut off valves for the complete supply to each unit are required, Division B, Sentence 7.6.1.6. Suites(1) Shut-off valves shall be installed in every suite in a building of residential occupancy as may be necessary to ensure that when the supply to one suite is shut off the supply to the remainder of the building is not interrupted.

• I live in a single-detached house, semi-detached house or a freehold street townhouse;

• I do not have a garden suite, lodging house or group home on my property already (Note: You can only have one Secondary Dwelling Unit on your property);
• I do not live in a house within the Ottawa River Floodplain, or on lands in a Natural Heritage Feature zone.
• I do not live within hazard lands, such as flood-prone or highly erosive areas, or areas with slope stability issues; (this is determined by the planner); and,
• my lot has adequate servicing to accommodate a secondary dwelling unit; including, but not limited to water supply, waste water disposal and electricity.

Yes, but in order to build a Secondary Dwelling Unit in a detached structure (e.g. garage) you must be able to meet all of the following zoning requirements:

• Your lot is large enough for an accessory building and is serviced by municipal water and sewer services.
• Your Secondary Dwelling Unit cannot be more than one storey; and,
• Your Secondary Dwelling Unit must be able to meet all applicable Zoning By-law provisions, such as minimum setbacks from lot lines.
• If do not have access to Municipal water & sewer services, your lot must be larger than 0.8 hectares (2 acres)
• Your detached Secondary Dwelling Unit will also need to meet the standards of the Ontario Building

All Secondary Dwelling Units must have their own separate entrance. The separate entrance may be from

the front, side or rear of the building, but it must meet the following requirements:

• The entrance cannot be from a garage, unless there is a separate main door with direct outdoor access;
• The entrance must be accessed by a minimum 1 metre wide path of travel between the building and any lot line; and,
• Safe entrance and exit of the Secondary Dwelling Unit must meet the requirements of the Ontario Building Code and the Ontario Fire Code.

You must supply parking for the Secondary Dwelling Unit in addition to the minimum 1 off-street parking space that is required for your home (the principal dwelling).

Please note the following when determining the number of parking spaces on your property:

• Parking spaces both inside the garage or outside on the driveway can be counted;
• Any spaces for parking in the boulevard area between the street and your front lot line will not be counted towards these requirements;
• Each exterior parking space must be a minimum of 2.5 metres wide and 5 metres long;
• If your property cannot provide enough parking right now, you might be able to widen your driveway to meet the required number of parking spaces;

Yes, but you may be required to demonstrate that the system has sufficient capacity for the Secondary Dwelling Unit. The Ministry of the Environment has rules for the quantity and quality of water that a private residential well must provide. The capacity and design of a private septic system is regulated by the Ontario Building Code. The minimum lot area is 8,000 m2 (approximately 2 acres).

On-site drainage and storm water management must be maintained or improved with the addition of a Secondary Dwelling Unit. For example, the construction of a side yard walkway has the potential to alter the way surface runoff flows to storm water management drains. A site grading plan may be required to ensure that any changes made to your property do not negatively impact grading and drainage on your property or your neighbours, to limit the possibility of flooding.

If your property cannot meet the zoning requirements for Secondary Dwelling Units, it may be possible to apply for approval of either a minor variance or a zoning by-law amendment depending on the circumstance. These processes are summarized as follows.

Minor Variance Application

• The minor variance process allows for a property owner to seek relief from a specific provision of the Township's zoning by-law subject to the approval of the Committee of Adjustment and no appeals being received. It will typically take about 2 months for your application to be processed. Additional details and the minor variance application form can be found online.

Zoning By-Law Amendment

• If the requested relief from the Township's Zoning By-Law is not determined to be minor, a site-specific zoning by-law amendment may be required, subject to Council approval and no appeals being received. This process typically takes about 3-4 months.

Please contact our Planning Department 613-735-6291 to discuss which whether an exception may be possible and which process best suits your situation.

It is strongly recommended that you hire a qualified designer. The Building Code requirements for Secondary Dwelling Units are complex. A qualified designer will help ensure that your plans meet all technical requirements, saving you time and money in the long run. The designer may be an architect, engineer or a person certified and registered with the Ministry of Municipal Affairs and Housing (MMAH). Designer qualifications can be viewed on the Ministry's on-line Public Registry (QuARTS).

Under the Ontario Building Code, the owner is responsible for all construction on your property. If you want your contractor or designer to apply on your behalf, you must provide written authorization, the permit will name you as the owner and correspondence from the Building Department will go to you also.

Once you have checked that your Secondary Dwelling Unit meets the zoning requirements, you can submit your Building Permit or Change of Use Application. Your Secondary Dwelling Unit must comply with the Ontario Building Code. Your building permit application will typically include the following:

• A site plan showing compliance with zoning requirements such as the number of parking spaces and the entrance path to the Secondary Dwelling Unit
• A floor plan of the existing or proposed Secondary Dwelling Unit
• Cross-section drawings of walls/ceilings and details of the materials and systems used
• Items to be shown on the plans for the Secondary Dwelling Unit include:
  • Entrance and exit
  • Room sizes and heights
  • Door and window sizes and types
  • Fire separations and sound transmission ratings
  • Heating and ventilation system(s)
  • Location of smoke alarms, and CO detectors
  • Plumbing facilities

After submitting your complete building permit application, it will typically take the Building Department about 10 business days to process it. You will be contacted if further information is required. You can start construction after obtaining the permit.

Permit fees are reviewed annually and subject to change. All fees are outlined in the Townships Fee Schedule.

You should design your Secondary Dwelling Unit so that it blends in with your neighbourhood. Any urban design guidelines that affect your property must be followed. The following are some things to keep in mind when designing your unit so that will be functional and blend in with your home and neighbourhood:

Design Considerations:

• Match any new windows, doors and materials (e.g. siding, brick, plaster, shingles, etc.) to the current ones on your home, especially at the front of the house
• Maintain current rooflines if you are adding on dormers or an addition to your second story (e.g. above your attached garage)
• Build a privacy fence or other landscape screening between your neighbours, especially if the Secondary Dwelling Unit has a side or rear entry
• Use permeable surfaces when providing additional parking
• Provide storage space for household items and garbage facilities
• Provide outdoor amenity space (e.g. deck or patio) for your tenants

Health and Safety Considerations:

• Accommodate individuals with mobility challenges with appropriate hallway and door widths, bathroom and kitchen fixture placement, stair configuration, etc.
• Ensure you have adequate outdoor lighting, while still minimizing the projection of light onto neighbouring properties
• Provide a hard/stable walkway to the Secondary Dwelling Unit entrance if it is not at the front of the house

Service Considerations:

• Separate electrical service, do you want to include hydro in the rent, or do you want to have them on a separate service & meter? There should be a separate breaker panel for the secondary dwelling unit, you don't want the tenants bothering you every time a breaker trips, what would they do if you were away?
• Will there be a separate heating system? Will they have their own gas service or propane tank? There should be a separate thermostat to control the heat in the secondary dwelling unit.
• There will have to be separate water service valves to the secondary dwelling unit, so the tenants can shut off the water to the unit in the event of a break or equipment malfunction.

After you have built your Secondary Dwelling Unit and had your final inspection from the Building Department, you must apply to register your Secondary Dwelling Unit. A complete application for registration includes the following:

• Completed Secondary Dwelling Unit Registration Form* + Copy of your Final Inspection Report = Legally registered Second Unit

*The property owner must declare the following on the registration form: That you are the property owner or the authorized agent.

There is an Application Fee of $120.00. Then there is a one-time registration fee of $200.00. There is also a $50.00 fee for a change in ownership, so the registry can be amended.

Yes, once you register your Secondary Dwelling Unit it will be assigned a secondary address of “Unit 2 or Unit B; your choice” (the address for the primary dwelling will stay the same). The address of “Unit 2 or Unit B” must be clearly visible to identify the primary entrance into the Secondary Dwelling Unit. Having a second municipal address will help emergency services such as police, fire and ambulance to act more quickly in an emergency. It will also make mail, delivery services hydro and gas billing more convenient and ensure that garbage and recycling is picked up from both residential units.

Yes, a list containing the addresses of legally registered Secondary Dwelling Units is available for in person viewing at our office located at 460 Witt Road. This list will also make it easier for tenants to identify whether a Secondary Dwelling Unit is legal, (and that it complies with building, fire and electrical codes).

The rights and responsibility of a landlord are outlined in the Residential Tenancies Act. This information for landlords in Ontario is available from the Landlord and Tenant Board.

All property owners must also follow the Township's Zoning By-Law and Ontario Building Code and Ontario Fire Code provisions, as well as the Township's Property Standards By-law, which establishes standards for the maintenance of properties and buildings, such as interior and exterior yard maintenance.
